Description
Introduction
SPF series fuel injection triple screw pumps are used to deliver diesel, lubricating oil, fuel oil, hydraulic oil or other lubricating fluids. The liquid medium must not contain any abrasive particles or substances that are chemically corrosive to the pump. Applicable temperature ≤120℃, viscosity 3-760cst, pressure ≤4.0Mpa.
Inlet and outlet flange
Import flange: PN16DIN2533(GB2555-81)
Export flange: PN40DIN2535(GB2555-81)
Feature
- Rotor hydraulic balance, low vibration, low noise.
- Stable output, no pulsation.
- Efficiency.
- It has a strong self-priming ability.
- The parts are designed in a series with strong versatility and have a variety of installation methods.
- Compact structure, small size, light weight, can work at a higher speed.
- The fuel pump used in the fuel system for conveying, pressurizing and fuel furnaces;
- Used as transmission and fuel pump in oil transmission systems;
- It can be used as a lubricating oil pump in all industrial fields;
- Used for hydraulic pumps in various hydraulic transmission devices;
Technical Specification
